Усилитель 4-канальный DLS CCi44
Number of channels 4
Amplifier class AB
Output power in 2 ohm 4 x 110 Watt
Output power in 4 ohm 4 x 85 Watt
Mono bridge mode 4 ohm 2 x 220 Watt
Damping factor >300
S/N ratio, A-weighted >110 dB
Frequency range 10 Hz - 60 kHz
Input sensitivity 1 - 4 Volt
Input impedance 6 kohm
Input impedance, high level 45 ohm
High level input with auto start Yes
Remote bass level control No
Low level output No
Remote phase shift control No
Integrated fan Yes
Filters channel A & B HP 50 - 500 Hz, LP 50 - 500 Hz
Filters channel C & D HP 50 - 500 Hz, LP 50 - 500 Hz
Power consumption (idle) 0,7 A
Power consumption (max) 64 A
Fuses use external fuse 60A
Dimension (W x D x H) 129 x 320 x 54 mm (5,1" x 12,6" x 2,1")
Weight 2,4 kg
Amplifier class AB
Output power in 2 ohm 4 x 110 Watt
Output power in 4 ohm 4 x 85 Watt
Mono bridge mode 4 ohm 2 x 220 Watt
Damping factor >300
S/N ratio, A-weighted >110 dB
Frequency range 10 Hz - 60 kHz
Input sensitivity 1 - 4 Volt
Input impedance 6 kohm
Input impedance, high level 45 ohm
High level input with auto start Yes
Remote bass level control No
Low level output No
Remote phase shift control No
Integrated fan Yes
Filters channel A & B HP 50 - 500 Hz, LP 50 - 500 Hz
Filters channel C & D HP 50 - 500 Hz, LP 50 - 500 Hz
Power consumption (idle) 0,7 A
Power consumption (max) 64 A
Fuses use external fuse 60A
Dimension (W x D x H) 129 x 320 x 54 mm (5,1" x 12,6" x 2,1")
Weight 2,4 kg
